ZGEMMA H2.8H COMBO SET TOP BOX
DVB-S2 DVB-T2 DVB-C H265 HEVC
Combo LINUX ENIGMA Set-Top Box kártyafogadóval. OpenAtv Szoftverrel gyárilag.
A készülék kezelése szoftverezése némi szakértelmet igényel, nem alapkészülék.
short user manual-english.pdf download
- High-performance Cortex A7 processor
- Hi3716MV431 Main chipset
- USB WIFI Stick ready MT7601U, Ralink 5370, 8192CU, RT2800
- More than 4.10x linux kernel
- DVB-S2X MultiStream + DVB-T2/C combo tuner built-in
- 512MB NAND Flash
- 1 Card Reader
- 1 x USB2.0
- 1x HDMI 2.0
- H.265 Main/Main 10@Level 4.1 high-tier
- H.264 BP/MP/HP@Level 4.2; MVC
- MPEG-1
- MPEG-2 SP@ML and MP@HL
- MPEG-4 SP@Levels 0–3, ASP@Levels 0–5, GMC, and MPEG-4 short
- Header format (H.263 baseline)
- AVS baseline@Level 6.0 and AVS+
- VC-1 SP@ML, MP@HL, and AP@Levels 0–3
- VP6/VP8
- 1-channel 1080p@60 fps decoding
- 10/100 Mbit Ethernet Interface
- Advanced EPG (Electronic Program Guide)
- User-friendly linux Menu system
- Full automatic service scan
- 3-layer OSD
- Various Channel Editing Programs
- Easy and fast software-upgrade via USB
- Low deep-standby power consumption under 1 W
- Parental Control
- Plugin Service
- Excellent sound quality in Dolby Digital
- OSD into many languages and graphics (Skins)
- Web interface, WEB Remote control
- DiSEqC 1.0 / 1.1 / 1.2 and USALS
- External power supply 12V 2A
certificate.pdf
Designed for set-top boxes, this SoC solution gives you FHD and HEVC in one cost-effective package. Its powerful Arm Cortex-A7 processor and TDE decode HD video in H.265, H.264, AVS+, MPEG-2, MPEG-4, VC-1, VP6, and VP8, while processing Dolby audio. Flexible connection with various peripheral interfaces optimizes the user experience in stream compatibility, smoothness, and live playback quality.
